Based on Android 4.4 operating system, the lightweight and rugged iData 95UHF features quickly and accurately UHF RFID data capture in batch. Supporting 3G and many other wireless transmission modes, it can transmit data in real time, enabling enterprises to manage business anytime anywhere easily.
Android-OS-based. UHF RFID reader. The lightest device in its class.
Compatible with versatile data capture modes and wireless transmission modes.
iData 95UHF goes far beyond your imagination
Adopting the most advanced handheld reader technology in the industry and the industry-class configuration,
iData 95UHF is built into an excellent data capture device, providing users with more convenient use and
smoother operation in addition to high performance.
Based on full understanding of enterprise mobility, each aspect of iData 95UHF,
including product design, parts selection, production and testing, is rigorous and
strict to ensure that each iData device is reliable and durable.
For users’benefits, iData fully considers users’customization requirements so that they can select or customize
devices more flexibly according to their business requirements.
| System Configuration | |
| Processor | Quad-core 1.3 GHz |
| Operating system | Android 10.0 |
| Memory (ROM+RAM) | 16GB+2GB |
| Expansion slot | Micro SD card, up to 256 GB |
| Display screen | 3.5-inch HVGA (960x640) |
| Camera | 8 MP autofocus lens, LED flash |
| Camera | 8 MP autofocus lens, LED flash |
| Flashlight | 800mA flashlight |
| Keyboard | 25 keys in total, front key *23, side scan key *2 (internal light-transmitting industrial IMD keyboard) |
| Battery | 3.7V 6000mAh Lithium Polymer battery, detachable *Executive standard: GB31241-2014 |
| Audio | Built-in microphone |
| Charging | Type-C charging and pin port charging, support 18W fast charge |
| Prompts | Vibrator alerts/LED/Audio notification |
| Vibrating motor | Built-in programmable vibration motor |
| Sensor | G-Sensor/Proximity sensor/Light sensor |
| Intercom function (optional) | Supporting one-button PTT calls |
| Structure parameters | |
| Dimension (LxWxD) | 189mm*70mm*43.5mm |
| Weight | 383g (including battery) |
| Communication transmission | |
| Wireless wide area network (Network frequency) |
2G：B2/B3/B5/B8 3G：WCDMA：B1/B5/B8，CDMA BC0，TD-SCDMA：B34/B39 4G：FDD-LTE：B1/B3/B5/B7/B8/B20，TDD-LTE：B34/B38/B39/B40/B41 |
| Wireless wide area network (Data service) |
GSM/GPRS/EDGE/CDMA/UMTS/HSPA/HSPA+/EVDO/WCDMA/TD-SCDMA/TDD-LTE/FDD-LTE |
| WLAN | Wi-Fi 802.11ac/a/b/g/n/r 5G PA (Dual-band Wi-Fi:2.4G+5G) |
| Bluetooth | Bluetooth 5.0+BLE |
| 通讯传输 | |
| GPS | GPS/AGPS/北斗/伽利略/GLONASS/QZSS |
| Operating Environment | |
| Working temperature | -20℃~60℃ *For your safety, please do not charge in a low temperature environment |
| Storage temperature | -40℃~70℃（Without battery） |
| Humidity | 0～95% (no condensation) |
| Drop specification | 1.5m concrete floor dropped several times |
| Roller drop specification | 500 times of roller drops from a height of 0.5 meters |
| Protection level | IP65 |
| Electrostatic protection | ±15KV (air discharge), ±8KV (contact discharge) |
| Scan engine | |
| Barcode | Support 1D/2D scanning engine |
| Scanning accuracy | ≥3.33mil |
| Scanning angle | Tilt ±60°, deflection ±60°, rotation 360° |
| Angular Field of View | Horizontal: 44.3°; Vertical: 28.4°; Diagonal: 51° |
| NFC (Optional) | |
| Motion tolerance | 8m/s |
| UHF RFID | |
| Protocol | ISO18000-6C/EPC Class1 Gen2 |
| working frequency | 902-928MHz |
| Power output | 1 W (<30 dBm) |
| Antenna | Circularly polarized 2 dBi / Linearly polarized 1.4 dBi |
| Reading distance | Up to 6m |
| Reading rate | Up to 200tags/s |
| Input/output Interface | |
| USB interface | Type-C (with earphone function) *1 |
| OTG interface | Supporting |
| Development support | |
| Development language | Java |
| API | iScan API (Scan Development Kit), Device API (Device Management/Configuration Development Kit), Android standard interface |
| Development tool | Eclipse/Android Studio |
| Accessories | |
| Standard accessories | Battery*1, Power adapter*1, Hand strap*1, Bottom charging cable*1, USB cable*1 |
| Optional accessories | Screen protector |
| Note | |
| 1 | As the product line is updating from time to time, the information in this document is subject to change without notice. |
