iData T1

Large-screen intelligent mobile terminal


It can bring strongly protected experience in touch control data acquisition
for your employees at the forefront of your business


"Light" but "strong"

The 5.5-inch full screen thin PDA that can be held in one hand with 18:9 screen design ratio,
supporting multitask split screen operation,
230G easy holding feeling, zero burden to carry,
and more convenient operation.


Strong protection

1.5m fall resistant, IP68 dustproof and waterproof, noise resistant, cold and heat resistant,
visible under strong screen light, gloves & wet and dry hand touch

t1 ip.png

Professional functions, all available


Enterprise Wi-Fi

Deep optimization, fast roaming, easy to handle more complex Wi-Fi scenarios.

主体 整屏.png

Secure identification

Face recognition, accurate, front-loading of 5 million + rear-loading of 13 million double photo design, and accurate face recognition function.

主体 整屏.png

fingerprint recognition

It can quickly identify fingerprint and unlock,
and support multiple fingerprint identification applications,
fully meeting the requirements of various mobile applications of enterprises.


Customizable one-click intercom PTT

(Customizable) Quickly implements "one-to-one "and "one-to-many "calls.


Basic functions, better performance


iData T1 Application scenario

T1 2.png

T1 Specifications

System Configuration
Processor Octa-core 2.0GHz high-performance processor
Operating System Android 10.0(GMS)
Memory (ROM+RAM) 64GB + 4GB (standard)
SIM
(eSIM: Not supported)
Two out of three SIM card slots, support dual SIM and dual standby
* Two out of three SIM card slots: two cards can be held at the same time, Nano SIM card + Nano SIM card /Nano SIM card +TF card

Wi-Fi Only:SIM not available, not supported
Expansion Slot Micro SD card (up to 256 GB)
Wi-Fi Only: Expansion slot not available
Display Screen 5.5-inch, resolution: 1440*720 pixels
Touch Screen Industrial capacitive screen, support wet-hand operation/glove mode/multi-touch/gesture operation
Camera 13MP rear camera, support auto-focus/PDAF, 5MP front camera
Flashlight 800mA flashlight
Keyboard 3 keys in total, side scan key*2, side power key*1
Battery 3.85V lithium battery, with 5000mAh, undetachable
Audio Built-in dual microphone (noise-canceling microphone)
Charging Method Type-C charging and pin port charging, support 10W fast charging
Reminder Vibration reminder/LED reminder/Audio reminder
Fingerprint Identification (Optional) Support back fingerprint recognition
Vibrating Motor Built-in vibrating motor
Sensor G-sensor/ Proximity sensor/Light sensor
Intercom Function (Optional) Supporting one-button PTT calls
Structure Parameter
Dimension (L*W*D) 157mm*74mm*13.6mm
Weight 230g (including the battery)
Communication Transmission
WWAN (Network Frequency) 2G:B2/B3/B5/B8
3G:WCDMA:B1/B5/B8,CDMA:BC0,TD-SCDMA:B34/B39
4G:FDD-LTE:B1/B3/B5/B7/B8/B20,TDD-LTE:B34/B38/B39/B40/B41

WIFI ONLY version: SIM not available, not supported
WWAN (Data Service) GSM/GPRS/EDGE/CDMA/UMTS/HSPA/HSPA+/EVDO/WCDMA/TD-SCDMA/TDD-LTE/FDD-LTE

WIFI ONLY version: SIM not available, not supported
WLAN Wi-Fi 802.11a/b/g/n/r/ac (2.4G + 5G dual-band Wi-Fi), support Wi-Fi 5G PA amplifier
Bluetooth Bluetooth 5.0, support BLE
GPS GPS/AGPS/BDS/Galileo/GLONASS/QZSS
Environmental Parameter
Working Temperature -20℃ - 60℃
*Do not charge under low temperature conditions for the safety Concerns
Storage Temperature -40℃ - 60℃(Without battery)
Humidity 0 - 95% (no moisture condensation)
Drop Specification Multiple drops to concrete floor from the height of 1.5m
Roller Drop Specification 1000 times of roller drops from a height of 0.5 meters
Ingress Protection IP68
ESD Protection ±15KV (air discharge), ±8KV (contact discharge)
Scanning Engine (Optional)
Barcode Type It can scan one-dimensional / two--dimensional barcodes
Scanning Accuracy ≥3.33mil
Scanning Angle Pitch: ±60°; Skew:±45°; Tilt:360°
View Angle Horizontal:44.3°,Vertical:28.4°,Diagonal:51°
Motion Error Tolerance 8m/s
NFC (Optional)
Working Frequency 13.56 MHz
Reading Distance Within 30 mm
Communication Protocol ISO14443A/14443B/15693
Communication Interface
USB Interface Type-C (with headset function) *1
OTG Interface Support
Development Support
Programming Language Java
API iScan API (Scanning Development Kits), Device API (Device Management/Configuration Development Kits), Android Standard Interface
Development Tool Eclipse/Android Studio
Accessories
Standard Accessories USB cable*1, hand strap *1, power adapter*1
Optional Accessories Single charging cradle, 4-slot charging cradle, fanny pack, protective case, protective film
Note
****** Due to irregular updates of the product line, the content is subject to change without notice.
