J16-BT

iData J16-BT

Zero constrain,more freedom.Wireless Bluetooth scanner


Bluetooth efficient transmission, free from the wire constrain

The scanner connects the base by Bluetooth 5.0; The transmission distance could reach up to 70m;
It supports wireless long-distant scanning,no constrain,free from the wire constrain;
The base connects the computer by USB, driver-free installation,simply insert and use.


PSSA/MSSA configuration system

The scanner can be connected by computer’s USB cable,
then you can use the PSSA configuration scanner
You can also connect the scanner by Bluetooth,
use MSSA configuration system to set up the scanner more easily


Humanized Voice Prompt

We adopts a 130dB high decibel speaker to guarantee the clear prompt sound in a noisy environment.
The humanized voice prompt would report immediately after your setting to ensure your actions have been done correctly.

图层 4 (1).png

Comprehensive reading ability

It’s easy to read barcodes including DPM barcodes in industry manufacturing,the reflective barcodes on metal, and the contaminated hard-to-recognized barcodes in hospitals etc.


High performance in Codec

It adopts high performance codec chips,with 60,000+software codec library,
which could read fast,decode accurately,and is able to read 3mil barcodes.


Multispectral dimming technology

It could adjust the light’s color temperature and brightness etc to get a clear picture
base on the environment and barcodes conditions
It’s able to read barcodes under the lowest contrast condition of 20%.

  • Comprehensive reading ability
  • High performance in Codec
  • Multispectral dimming technology

Flexible charging, long lasting battery life

The scanner equips with 2600mAH powerful battery, which can scan up to 100,000+ times,and works more than 12 hours per charge.
The base charger can charge the scanner whenever you place it into the base. It keeps high battery capacity all the time.
It adopts an excellent battery management system, which supports low consumption mode,reduce unnecessary power waste.


J16-BT Specifications

Performance Parameter
Light Sensor 1280*1080 pixels
Light Source WHITE, RED, BLUE
Scanning Performance
Scanning Accuracy ≥3mil
Scanning Angle Pitch: ±70°; Skew:±60°; Tilt:360°
View Angle Horizontal:44.3°,Vertical:28.4°,Diagonal:51°
Minimum Reading Contract 15%
Motion Tolerance 13mil UPC 2m/S (Support up to 8m/s in high motion tolerance mode)
Physical Parameter
Size (H*W*D) 174.69mm(H)*84.32mm (W) *64.68mm (D)
Weight Scanner: 215g; Base: 193g
Working Voltage 4.5V~5.5V(DC)
Current 40mA (Base uncharged)
Interface USB-HID,USB-CDC,RS232
Reminder Speaker(voice) reminder/LED reminder/Vibration reminder
Housing Material PC+ABS
Environment Parameter
Working Temperature 0℃~50℃
Storage Temperature -20℃~70℃
Humidity 5%~95%(No condensation)
Ingress Protection IP52
Ambient Light 0Lux~100000Lux
Drop Specification Multiple drops to concrete floor from the height of 1.8m
ESD Protection ±15KV (air discharge), ±8KV (contact discharge)
Wireless Transmission Performance BT
Bluetooth Bluetooth 5.0
Range 2402MHz~2480MHz
Transmission Distance Up to 70m in open space
Communication Mode Real-time mode/Batch mode
Scanning Configuration
Battery 2600mAh
Charging Time 5 Hour(5V/2A)
Working Time ≥12h
Scan Times Up to 100,000 times for a single charge
Corresponding Regulations
Electric Safety IEC 60950
Environmental Specification RoHS directive 2011/65/EU,GB/T 26572
LED Safety IEC 62471:2006
EMI/RFI FCC Part 15 Class B,EN 55032:2015,EN 55035:2017
Decoding Range
3.33mil Code128 XD (Ultra-high Density):0.5cm~3cm (0.016" to 0.1")
HD (High Density):2.5cm~14cm (0.98" to 5.51")
SR (Standard Range):9.5cm~16.0cm (3.74" to 6.30")
10.83mil Code128 XD (Ultra-high Density):0.5cm~5cm (0.016" to 0.16")
HD (High Density):0.5cm~19cm (0.2" to 7.48")
SR (Standard Range):2.0cm~50.0cm (0.79" to 19.69")
5.83mil QR Code XD (Ultra-high Density):0.5cm~3cm (0.016" to 0.1")
HD (High Density):3.5cm~8.5cm (1.38" to 3.35")
SR (Standard Range):11.0cm~13.5cm (4.33" to 5.31")
20.83mil QR Code XD (Ultra-high Density):0.5cm~6.5cm (0.016"~0.21")
HD (High Density):1.5cm~21cm (0.59" to 8.27")
SR (Standard Range):4.0cm~95.0cm (1.57" to 37.40")
Code System
1D Codabar, Code 11,Code 128,Code 32,Code 39,Code 93,EAN 13,EAN 8,UPC-A,UPC-E,IATA 2 of 5, Interleaved 2 of 5,Matrix 2 of 5,Straight 2 of 5, MSI/PIessey,GS1 DataBar, etc.
2D Aztec, Data Matrix, MicroPDF 417,PDF 417,QR,Micro QR, Grid Matrix, etc.
Accessories
Standard Accessories USB cable*1, user manual*1, power cord*1
Optional Accessories Cradle, serial cable
Note
****** As the product line is updating from time to time, the information in this document is subject to change without notice.
